8
ANGENIEUX OPTIMO ULTRA COMPACT STANDARD
CONFIGURATION
FF/VV
CONFIGURATION
U35
Zoom ratio
2,7x
2.7x
Focale Length (mm)
37-102
28-76
Maximum aperture
T2.9
T2.2
Minimum Object Distance (ft)/(m)
2' / 0,6m
2' / 0.6m
Image coverage (mm)
46,3
34.6
Weight (kg / lbs)
2.5 / 5.51
2.5 / 5.51
Front diameter (mm)
114
114
Max diameter (mm)
114
114
Length (front to mount) (mm)
235mm = 9 1/4 in
235mm = 9 1/4 in
Mounts
PL
PL
Internal focus
Yes
Yes
Iris scales 2 opposite scales
2 opposite scales
2 opposite scales
Angular rotation of iris ring (°)
71,4°
71.4°
Iris gear drive
126 teeth, pitch 32
126 teeth, pitch 32
Zoom scales
2 opposite scales
2 opposite scales
Angular rotation of zoom ring (°)
150°
150°
Zoom gear drive
126 teeth, pitch 32
126 teeth, pitch 32
Focus scales
metric or footage
marked
metric or footage
marked
Angular rotation of focus ring (°)
310°
310°
Focus gear drive
126 teeth, pitch 32
126 teeth, pitch 32
Angular Field of View
Focal Length
37-102
28-76
Horizontal angular field of view
57.3° / 22.7°
57.3° / 22.7°
Object dimensions at MOD (mm)
449 x 237 / 159 x 84
447 x 224 / 160 x 84
2 – Technical information
(for Full-Frame :
40.96x21.6mm)
(for U35 :
30.7x15.8mm)
