19
THE BELOW PROCEDURE APPLIES FOR F18-F21-F24-F28
- Untighten and remove the eight Phillips screws (0) holding the front ring (1). Pull out the front ring (1). Note: only four screws (0) for F18.
- Untighten and remove the three Phillips screws (2). Pull out the front engraved ring (3)
- Untighten the seven Phillips screws (6) without removing them. Pull out the focus ring (4)
- Replace the focus ring or flip it by 180° for feet or meter use and tighten the Phillips screws (6) in contact
- Re-install the front engraved ring (3) and the front ring (1)
- Check and adjust the focus ring position to match the engraved distances and tighten uniformly the seven Phillips screws (6)
- Tighten all the screws in contact with a removable threadlock
0
2
3
4
5
6
1
