American DJ® - www.americandj.com - X-Color LED Plus Instruction Manual Page 11

American DJ® - www.americandj.com - X-Color LED Plus Instruction Manual Page 12

Operating Modes: The X-Color LED Plus can operate in three

different modes. This next section will detail the differences in

the operating modes.

• Stand alone mode -

The unit will react to sound, chasing through the built-in programs.

• Master/Slave mode -

You can daisy chain up to 16 units together to get a synchronized

light show without the need of an external controller. The units will

react to sound chasing through the several built-in programs.

• DMX control mode -

This function will allow you to control each individual fixtures traits

with a standard DMX-512 controller such as the Elation® Show

Designer.

™

Universal DMX Control: This function allows you to use a Elation®

universal DMX-512 controller to control the chases and patterns,

dimmer and strobe. A DMX controller allows you to create unique

programs tailored to your individual needs.

1. The X-Color LED Plus is a three DMX channel DMX fixture. See

page 13 for detailed description of the DMX traits.

2. To control your fixture in DMX mode, follow the set-up procedures

on pages 5-7 as well as the set-up specifications that are includ-

ed with your DMX controller.

3. Use the controller’s faders to control the various DMX fixture traits.

4. This will allow you to create your own programs.

5. Follow the instruction on page 8 to set the DMX address.

6. For longer cable runs (more than a 100 feet) use a terminator on

the last fixture.

7. For help operating in DMX mode consult the manual included

with your DMX controller.

Sound Active Mode: This mode allows either single unit or several

units linked together, to run to the beat of the music.

1. Tap the MENU button until “SOUN” is displayed, and press

ENTER. Tap the UP or DOWN buttons so that “ON” is dis

played and press ENTER.

2. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.

X-Color LED Plus Operation

exit

RSET - Use this function to reset the unit.

1. Tap the MENU button until “RSET” is displayed, press ENTER.

2. The xture will now reset.

X-Color LED Plus System Menu
