American DJ® - www.americandj.com - X-Color LED Plus Instruction Manual Page 13 American DJ® - www.americandj.com - X-Color LED Plus Instruction Manual Page 14

X-Color LED Plus Operation X-Color LED Plus DMX Traits

Master-Slave Operation (Sound Active): This function will allow

you to link up to 16 units together and operate without a controller. The

units will be sound activated. In Master-Slave operation one unit will

act as the controlling unit and the others will react to the controlling

units programs. Any unit can act as a Master or as a Slave.

1. Using approved DMX data cables, daisy chain your units togeth-

er via the XLR connector on the rear of the units. Remember the

Male XLR connector is the input and the Female XLR connector

is the output. The rst unit in the chain (master) will use the female

XLR connector only - The last unit in the chain will use the male

XLR connector only. For longer cable runs we suggest a termina-

tor at the last fixture.

2. On the Master unit find your desired show and set that show by

pressiing the ENTER button.

3. On the slave units tap the MENU button until “SLND” is dis-

played, select your desired Slave mode and Press ENTER.

4. The slave units will now follow the Master unit.

5. The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.

X-Color LED Plus UC3 Control

Channel Value Function

1 COLORS

0 - 14 WHITE

15 - 28 ORANGE

29 - 42 BLUE

43 - 56 GREEN

57 - 70 YELLOW

71 - 84 PINK

85 - 98 LIGHT BLUE

99 - 112 LIGHT GREEN

113 - 127 LIGHT YELLOW

128 - 255 RAINBOW EFFECT SLOW - FAST

2 0 - 255 DIMMER 0% - 100%

3 SHUTTER/STROBE

0 - 7 BLACKOUT

8 - 15 SHUTTER OPEN

16 - 131 STROBING SLOW - FAST

132 - 139 SHUTTER OPEN

140 - 180 SHUTTER SLOW OPEN - FAST CLOSE

181 - 189 SHUTTER OPEN

190 - 231 SHUTTER FAST OPEN - SLOW CLOSE

232 - 239 SHUTTER OPEN

240 - 247 RANDOM STROBE

248 - 255 SHUTTER OPEN

The optional UC3 Controller (not included) may be used to con-

trol different functions including blackout.

Stand By Blackout the unit

Function 1. Sync. Strobe

2. Async strobe

3. Sound Strobe

Select Color

Mode Sound (LED OFF) Show (LED On)
