©American Audio® - www.americanaudio.us - MX-1400 Instruction Manual Page 14
player.
33. channeL 4: Line 4 input Jacks - These Jacks are used for line level inputs. Connect CD
players or Tape Decks to line level inputs. Line level musical instruments with stereo outputs such as
Rhythm Machines or Samplers should also be connected to line level inputs. The red colored RCA
jack represents the right channel input and the white represents the left channel input. Input volume
will be controlled by the channel four fader. Do not connect turntables to these jacks, turntables
should only be connected to “Phono” inputs.
34. channeL 3: Line 3 input Jacks - DO NOT CONNECT TURNTABLES TO THESE JACKS!
CD players, Tape Decks and other line level instruments may be connected to these jacks. The red
colored RCA jack represents the right channel input and the white represents the left channel input.
Input volume will be controlled by channel three fader. The channel SOURCE SELECTOR KNOB (4)
must be in the "Line 3" position, to monitor any source connected to these jacks.
35. channeL 3: auX 3 input - The type of input must directly reect the selected mode of the
LINE LEVEL SELECTOR SWITCH (44). CD players, Tape Decks and other line level instruments may
only be connected to these jacks as long as the LINE LEVEL SELECTOR SWITCH (44) is in the “AUX
3” position. Never connect line level instruments (CD players, tape decks, etc.) to these jacks when
the LINE LEVEL SELECTOR SWITCH (44) is in the “PHONO 3” position, THIS MAY SERIOUSLY
DAMAGE YOUR MIXER! The red colored RCA jack represents the right channel input and the white
represents the left channel input. Input volume will be controlled by the channel three fader. The
channel SOURCE SELECTOR KNOB (4) must be in the "Phono 3/Aux 3" position, to monitor any
source connected to these jacks.
36. Gnd (Ground terMinaL) - Be sure to connect turntable ground leads to either or both of
the two available ground terminals. This will reduce the humming and popping noises associated
with magnetic phono cartridges.
37. channeL 2: Line 2 input Jacks - DO NOT CONNECT TURNTABLES TO THESE JACKS!
CD players, Tape Decks and other line level instruments may be connected to these jacks. The red
colored RCA jack represents the right channel input and the white represents the left channel input.
Input volume will be controlled by channel three fader. The channel SOURCE SELECTOR KNOB (4)
must be in the "Line 2" position, to monitor any source connected to these jacks.
38. channeL 2: phono 2/auX 2 input - The type of input must directly reect the selected
mode of the LINE LEVEL SELECTOR SWITCH (44). Turntables equipped with MM pickup cartridge
(All DJ turntable use MM pick-up cartridges) may be connected to these jacks as long as the LINE
LEVEL SELECTOR SWITCH (44) is in the “PHONO 2” position. CD players, Tape Decks and other
line level instruments may only be connected to these jacks as long as the LINE LEVEL SELEC-
TOR SWITCH (44) is in the “AUX 2” position. Never connect line level instruments (CD players, tape
decks, etc.) to these jacks when the LINE LEVEL SELECTOR SWITCH (44) is in the “PHONO 2” posi-
tion, THIS MAY SERIOUSLY DAMAGE YOUR MIXER! The red colored RCA jack represents the right
channel input and the white represents the left channel input. Input volume will be controlled by the
channel three fader. The channel SOURCE SELECTOR KNOB (4) must be in the "Phono 2/Aux 2"
position, to monitor any source connected to these jacks.
39. channeL 1: Line 1 input Jacks - DO NOT CONNECT TURNTABLES TO THESE JACKS!
CD players, Tape Decks and other line level instruments may be connected to these jacks. The red
colored RCA jack represents the right channel input and the white represents the left channel input.
Input volume will be controlled by channel three fader. The channel SOURCE SELECTOR KNOB (4)
must be in the "Line 1" position, to monitor any source connected to these jacks.
MX-1400 CONTROLS aNd FUNCTiONS cont.
