©American Audio® - www.americanaudio.us - MX-1400 Instruction Manual Page 13
29. channeL 4 pLayer controL - This jack is used to control the “Q-Start” function between the
mixer and a compatible American Audio® or American DJ® CD Player. Using the mini plug included
with your CD player, connect from the CD player controller out jack to this jack. Channel 4 “Q-Start”
functionallity will be controlled by the left side of the Crossfader (16). For more information on
“Q-Start” functionallity refer to the user manual included with your CD player. Be sure to only use
the mono tip mini plug included with your CD player to avoid damage to the mixer and/or the CD
player.
30. channeL 3 pLayer controL - This jack is used to control the “Q-Start” function between the
mixer and a compatible American Audio® or American DJ® CD Player. Using the mini plug included
with your CD player, connect from the CD player controller out jack to this jack. Channel 3 “Q-Start”
functionallity will be controlled by the left side of the Crossfader (16). For more information on
“Q-Start” functionallity refer to the user manual included with your CD player. Be sure to only use
the mono tip mini plug included with your CD player to avoid damage to the mixer and/or the CD
player.
31. channeL 2 pLayer controL - This jack is used to control the “Q-Start” function between the
mixer and a compatible American Audio® or American DJ® CD Player. Using the mini plug included
with your CD player, connect from the CD player controller out jack to this jack. Channel 2 “Q-Start”
functionallity will be controlled by the right side of the Crossfader (16). For more information on
“Q-Start” functionallity refer to the user manual included with your CD player. Be sure to only use
the mono tip mini plug included with your CD player to avoid damage to the mixer and/or the CD
player.
32. channeL 1 pLayer controL - This jack is used to control the “Q-Start” function between the
mixer and a compatible American Audio® or American DJ® CD Player. Using the mini plug included
with your CD player, connect from the CD player controller out jack to this jack. Channel 1 “Q-Start”
functionallity will be controlled by the left side of the Crossfader (16). For more information on
“Q-Start” functionallity refer to the user manual included with your CD player. Be sure to only use
the mono tip mini plug included with your CD player to avoid damage to the mixer and/or the CD
REAR PANEL
MX-1400 CONTROLS aNd FUNCTiONS cont.
49
51
333229 3430 31
45 4350 48 47 46
41 42363638373635 4039
444444
