40. channeL 1: phono 1/auX 1 input - The type of input must directly reect the selected
mode of the line leVel seleCtor switCh (44). Turntables equipped with MM pickup cartridge
(All DJ turntable use MM pick-up cartridges) may be connected to these jacks as long as the line
leVel seleCtor switCh (44) is in the “PHONO 1” position. CD players, Tape Decks and other
line level instruments may only be connected to these jacks as long as the line leVel seleC-
tor switCh (44) is in the “AUX 1” position. Never connect line level instruments (CD players, tape
decks, etc.) to these jacks when the line leVel seleCtor switCh (44) is in the “PHONO 1” posi-
tion, this May seriously daMage your Mixer! The red colored RCA jack represents the right
channel input and the white represents the left channel input. Input volume will be controlled by the
channel three fader. The channel sourCe seleCtor Knob (4) must be in the "Phono 1/Aux 1"
position, to monitor any source connected to these jacks.
41. Mic attenuator - This knob is used to adjust the MIC 3 input level.
42. Microphone 3 connector - This jack is used to a connect a microphone to the mixer.
Connect you microphone via this 1/4 inch (6.3mm) jack. This microphone will be controlled through
the channel 3 fader. The channel 3 EQ will also effect the microphone output. Be sure to ip the
sourCe seleCtor Knob (4) to the “MIC 3” position to operate this microphone’s input signal.
43. BaLanced XLr Master output Jacks - The Master Output includes a pair of XLR
Balanced jacks as well as a pair of rCa unbalanCed jaCKs (47). The 3-pin XLR jacks send a
high current balanced output signal. These jacks should be used when you will be driving an amp or
other audio equipment with a balanced input, or whenever you will be running a signal line greater
than 15 feet. Always, use these jacks whenever possible.
44. channeL Line LeveL seLector sWitches - These switches are used to change the volt-
age line levels of there respected Phono / Aux RCA inputs jacks. When connecting turntables with
magnetic cartridges to these jacks be sure the corresponding switch is in the “PHONO” position,
and when using line level input devices be sure this switch is in the “AUX” position. Always be sure
main power is shut off before change the position of the Line Level Selector Switch.
45. Booth BaLanced XLr output Jacks - The Booth Output 3-pin XLR jacks send a high
current balanced output signal. These jacks should be used when you will be driving an amp or
other audio equipment with a balanced input, or whenever you will be running a signal line greater
than 15 feet. Always, use these jacks whenever possible.
46. rec output Jacks - This is a low current unbalanced output source designed for various
tape and CD recorders. The Record Out (REC OUT) level is dictated by the Channel fader leVel
(23), it is not inuenced by the Master VoluMe Control (14).
47. rca Master outputs - The Master Output includes a pair xlr balanCed jaCKs (43)
as well as a pair of RCA Unbalanced Jacks. The RCA jacks send a low current unbalanced output
signal. These jacks should only be used for shorter cable runs to signal processors or looping to
another mixer. For cable runs greater than 15 feet use the xlr balanCed jaCKs (43).
48. diGitaL output - This jack is used to send a stereo digital output siginal to a digital input
device.
49. triM output - This knob is used to adjust the maximum voltage output level. Output voltage
wil range from 0v ~ 9v. This function may be used to limit the maximum siganl output level.
50. ac connection - This connector is used to supply main power to the unit via the included
detachable power cord. The power connection uses an I.E.C. type connector, use only the supplied,
©American Audio® - www.americanaudio.us - MX-1400 Instruction Manual Page 15
MX-1400 CONTROLS aNd FUNCTiONS cont.
