©American Audio® - www.americanaudio.us - 10MXR BT Instruction Manual Page 12
10MXR BT CONTROLS aNd FUNCTiONS
22. ChanneL 1: LIne 2 InpUts - These Jacks are used for line level inputs. CD players, Tape
Decks and other line level instruments may be connected to these jacks. The red colored RCA jack
represents the right channel input and the white represents the left channel input. Input volume will
be controlled by the channel one fader. The channel SOURCE SELECTOR SWITCH (1) must be in
the “LINE 2” position, to monitor any source connected to these jacks. Do not connect turntables to
these jacks, turntables should only be connected to “Phono” inputs.
23. ChanneL 2: LIne 3/phono 1 InpUts - The type of input must directly reect the selected
mode of the CHANNEL LINE LEVEL SELECTOR SWITCH (17). CD players, Tape Decks and other
line level instruments may be connected to these jacks. The red colored RCA jack represents the
right channel input and the white represents the left channel input. Input volume will be controlled
by channel two fader. Turntables equipped with MM pickup cartridge (All DJ turntable use MM pick-
up cartridges) may be connected to these jacks as long as the CHANNEL LINE LEVEL SELECTOR
SWITCH (17) is in the “PHONO” position. When CD players, Tape Decks and other line level instru-
ments are connected to these jacks the CHANNEL LINE LEVEL SELECTOR SWITCH (17) is in the
“LINE” position. Never connect line level instruments (CD players, tape decks, etc.) to these jacks
when the CHANNEL LINE LEVEL SELECTOR SWITCH (17) is in the “PHONO” position, THIS MAY
SERIOUSLY DAMAGE YOUR MIXER! The channel SOURCE SELECTOR SWITCH (1) must be in the
“Phono 1/Line3” position, to monitor any source connected to these jacks.
24. ChanneL 2: LIne 4 InpUts - These Jacks are used for line level inputs. CD players, Tape
Decks, and other line level instruments may be connected to these jacks. The red colored RCA jack
represents the right channel input and the white represents the left channel input. Input volume will
be controlled by the channel two fader. The channel SOURCE SELECTOR SWITCH (1) must be in
the “LINE 4” position, to monitor any source connected to these jacks. Do not connect turntables to
these jacks, turntables should only be connected to “Phono” inputs.
25. ChanneL 3: LIne 5/phono 2 InpUts - The type of input must directly reect the selected
mode of the CHANNEL LINE LEVEL SELECTOR SWITCH (17). CD players, Tape Decks and other
line level instruments may be connected to these jacks. The red colored RCA jack represents the
right channel input and the white represents the left channel input. Input volume will be controlled by
channel three fader. Turntables equipped with MM pickup cartridge (All DJ turntable use MM pick-
up cartridges) may be connected to these jacks as long as the CHANNEL LINE LEVEL SELECTOR
SWITCH (17) is in the “PHONO” position. When CD players, Tape Decks and other line level instru-
ments are connected to these jacks the CHANNEL LINE LEVEL SELECTOR SWITCH (17) is in the
“LINE” position. Never connect line level instruments (CD players, tape decks, etc.) to these jacks
when the CHANNEL LINE LEVEL SELECTOR SWITCH (17) is in the “PHONO” position, THIS MAY
SERIOUSLY DAMAGE YOUR MIXER! The channel SOURCE SELECTOR SWITCH (1) must be in the
“Phono 2/Line5” position, to monitor any source connected to these jacks.
26. ChanneL 3: LIne 6 InpUts - These Jacks are used for line level inputs. CD players, Tape
Decks, and other line level instruments may be connected to these jacks. The red colored RCA jack
represents the right channel input and the white represents the left channel input. Input volume will
be controlled by the channel three fader. The channel SOURCE SELECTOR SWITCH (1) must be in
the “LINE 6” position, to monitor any source connected to these jacks. Do not connect turntables to
these jacks, turntables should only be connected to “Phono” inputs.
27. Booth rCa oUtpUt JaCks - These RCA jacks send a low current unbalanced output signal
and are controlled by the BOOTH LEVEL (5) volume control. These jacks should only be used for
shorter cable runs to signal processors or looping to another mixer.
