©American Audio® - www.americanaudio.us - 10MXR BT Instruction Manual Page 13
10MXR BT CONTROLS aNd FUNCTiONS
28. BaLanCed XLr Master oUtpUt JaCks - The Master Output 3-pin XLR jacks send a high
current balanced output signal. These jacks should be used when you will be driving an amp or
other audio equipment with a balanced input, or whenever you will be running a signal line greater
than 15 feet. Always, use these jacks whenever possible.
22. aC ConneCtIon - This connector is used to supply main power to the unit via the included
detachable power cord. The power connection uses an I.E.C. type connector, use only the supplied,
polarized AC power cord. Use only a power cord that matches this type of connection. Be sure to
only connect this unit to a power outlet that matches the printed power label on the unit. Never use
a power cord when the ground prong has been removed or broken o. The ground prong is used to
reduce the risk of electrical shock in case of an electrical short. This cord is designed to t in one
direction only. Do not attempt to force a cord if it does not t, be sure the cord is being inserted
properly.
FUse hoLder – This housing stores the 0.5 amp GMA protective fuse. Always replace with
the exact same type fuse, unless otherwise instructed, by an authorized American Audio
® service
technician. Replacing with any other type of fuse than that of the recommended fuse will void your
unit warranty.
23. MaIn poWer sWItCh - This is the main power ON/OFF button. Before main power is applied,
be sure you have made all connections to the mixer. Also be sure your amplier(s) is(are) tuned o.
Remember to avoid damaging pops to the speakers, the mixer is turned on rst and turned o last.
When the Bluetooth™ LED is off the status is off and not connected to any device. Follow the instruc-
tions below to connect to a Bluetooth™ device.
1. Activate you Bluetooth™ and look for the device “10MXRBT”.
2. Press and hold the Bluetooth™ Pairing button (1). Hold the button down until the LED begins to
blink quickly. When the LED stays lit the unit should be paired to your Bluetooth™ signal. As
long the unit is connected, the LED will stay lit.
3. You can now begin to play music through your device.
4. To disconnect, press and hold the Bluetooth™ Pairing button (1), until the LED turns off.
10MXR BT BLUETOOTh™ PaiRiNG
