3 UNO-148 User Manual
Chapter 1 Overview
1.4 Hardware Specifications
1.4.1 General
1.4.2 System Hardware
Table 1.1: General Specifications
Dimensions (W x D x H) 45 x 140 x 200 mm
Weight (Net) 1.5 kg
Mounting DIN-rail
Power Requirement 10 - 36VDC
Power Consumption 26 W (typical), 60 W (max)
Table 1.2: System Hardware
BIOS AMI UEFI 256 Mbit
Watchdog Timer Programmable 255-level timer interval, from 1 to 255 sec
Hardware Security TPM 2.0
Processor 11th Gen Intel® Core™ 1.8 GHz (up to 4.4 GHz)
Memory
2 Slots, Built-in 8 GB DDR4 3200 MHz (default 8 GB single
slot, max. up to 32 GB per slot)
Graphics Engine
Intel® Iris® Xe (supports i5 & i7 CPU)
Intel® UHD Graphics (supports i3 CPU)
Ethernet
2 x 10/100/1000BASE-T Fast Ethernet (RJ-45)
1 x 10/100/1000/2500BASE-T Fast Ethernet (RJ-45)
LED Indicators
1x Power: Green-S0, Orange S3 or S5
1x RUN: Green-Programmable (PLED)
1x BTR: RED-RTC Battery Low
Communication M.2 slot for B-Key and E-Key
Storage
1 x M.2 M-Key 2280 NVMe SSD (PCIe x4 Signal)
1 x M.2 B-Key 2242 (SATA Signal)
Expansion
1 x M.2 B-key 3042 or 3052 Module (USB 3.2 Gen 2 Signal)
1 x Nano SIM card slot for B-Key use
1 x M.2 E-Key 2230 WiFi module (PCIe / USB 2.0 Signal)
1 x Mini PCIe (PCIe / USB 2.0 Signal)
Note! The M.2 B-Key can support either 2242 storage (w/ SATA signal) or
3042/3052 Module (w/ USB signal).
