UNO-148 User Manual 4
1.4.3 I/O Interfaces
1.4.4 Environment
1.4.5 Certification
Table 1.3: I/O Interfaces
Serial Ports
4 x RS-232/422/485 (terminal block), 50 ~115.2 kbps
(Isolation Protection: 2500 VDC)
LAN Ports
1x Intel® I225 Ethernet Chip
1x Intel® I219 Ethernet Chip
1x Intel® I210 Ethernet Chip
Speed
2 x 10/100/1000BASE-T Fast Ethernet (RJ-45)
1 x 10/100/1000/2500BASE-T Fast Ethernet (RJ-45)
USB Ports 3 x USB 3.2 Gen 2, and 1 x USB 2.0 (Type-A)
Isolated DIO
8-ch digital input, 8-ch digital output (Isolation Pro-
tection: 2500VDC)
Input Voltage (Wet Contact)
Logic 0: 10 ~ 30 VDC
Logic 1: 0 ~ 3 VDC
Input Voltage (Dry Contact)
Logic 0: Shorted to GND
Logic 1: Open
Digital Output
Output Voltage: 5 ~ 30 VDC
Output Capability Sink: 500 mA max./channel
Displays 2 x DP 1.4, up to 7680x3480 (4K) @ 60Hz
Power Connector 1 x 2 Pin (terminal block)
Table 1.4: Environment
Operating Temperature -20 ~ 60 °C (-4 ~ 140 °F) with 0.7 m/s airflow
Storage Temperature - 40 ~ 85 °C (-40 ~ 185 °F)
Relative Humidity 95% RH @ 40 °C / 104 °F, non-condensing
Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11 ms
Vibration Protection
Operating, IEC 60068-2-64, 4 Grms, random, 5 ~ 500 Hz,
1hr/axis (SSD)
Operating, IEC 60068-2-64, 0.3 Grms, random, 5 ~ 500
Hz, 1hr/axis (HDD)
Table 1.5: Certification
Certification CE, FCC, CB, UL 61010-2-201, BSMI
