Je bekijkt pagina 14 van 86
UNO-148 User Manual 2
1.1 Introduction
Advantech's UNO-100 series are DIN-rail integrated controllers that feature a modu-
lar design for flexible configuration according to specific usage requirements. UNO-
148 is equipped with an 11th Generation Intel
®
Core™ i Processor (standard 1.8
GHz, optional up to 4.4 Ghz) with 8 GB DDR4 RAM, and 3 x LAN, 4 x COM, 3 x USB
3.2 Gen 2, 1 x USB 2.0, 8 x DI, 8 x DO and 2 x DP 1.4. The controller also supports 1
x full size Mini PCIe, 1 x M.2 (B-Key), 1 x M.2 (M-Key), 1 x M.2 (E-Key), and 1 x nano
SIM card for expansion such as Advantech’s iDoor technology for integrating addi-
tional industrial Fieldbus, wireless communication, I/O, and peripheral modules.
1.2 Safety Precautions
Below are a few safety precautions for preventing injury when making connections. In
most cases, users can use a standard cable for connection.
1.3 Packing List
Please refer to the below packing list:
UNO-148 (with DIN-rail mount)
2 x 10-pin plug-in block for COM port
1 x 20-pin plug-in block for DIO
1 x 2-pin plug-in for Power
1 x earth-ground cable
Quick Start Guide
Warranty card
If anything is missing or damaged, contact your distributor or sales representative
immediately.
Warning! Always disconnect the power cord from the chassis before manual han-
dling. Do not connect the chassis while the system power is on. A sud-
den rush of power can damage sensitive electronic components. Only
experienced electronics personnel should open the chassis.
Warning! Toujours à la terre pour éliminer toute charge d'électricité statique avant
toucher UNO-148. Appareils électroniques modernes sont très sensi-
bles à charges d'électricité statique. Utilisez un bracelet antistatique à
tout moment. Placez tous composants électroniques sur une surface
antistatique ou dans un statique-sac blindé.
Caution! Always ground yourself to remove any static electric charge before
touching UNO-148. Modern electronic devices are very sensitive to
static electric charges. Use a grounding wrist strap at all times. Place all
electronic components on a static-dissipative surface or in a static
shielded bag.
Caution! Toujours débrancher le cordon d'alimentation de votre boîtier lorsque
vous êtes travailler. Ne branchez pas lorsque l'appareil est allumé. Un
afflux soudain de puissance peut endommager les composants électro-
niques sensibles. Seulement connu personnel de l'électronique
devraient ouvrir le châssis.
