5 PCE-5133/5033 User Manual
Chapter 1 Hardware Configuration
1.4 Jumpers and Connectors
Connectors on the PCE-5133/5033 single host board link it to external devices such
as hard disk drives and a keyboard. In addition, the board has a number of jumpers
used to configure the system for your application.
The tables below list the function of each of the board jumpers and connectors. Later
sections in this chapter give instructions on setting jumpers. Chapter 2 gives instruc-
tions for connecting external devices to your motherboard.
Table 1.1: Jumpers
Label Function
JCMOS1 CMOS clear
JME1 Clear ME data
JWDT1+JOBS1 Watchdog timer output selection and OBS alarm
JPCICLK PCI clock selection
Table 1.2: Connectors
Label Function
USB2C1 USB2 port
USB3C1 USB3 port
USB3C2 USB3 port
LAN1 Intel I226LM (PCE-5133); Intel I226V (PCE-5033)
LAN2 Intel I226LM (PCE-5133); Intel I226V (PCE-5033)
VGA1 VGA connector
KBMS2 Internal PS/2 keyboard and mouse connector
HDAUD1 Advantech HD audio module expansion pin-header
SPI_TPM1 SPI expansion pin header for TPM module
Sysfan1 4 PIN fan power connector for supporting PWM or DC fan
LANLED1 LANLED
USB2A1 USB port
USB3H1 USB3 port
USB3H2 USB3 port (PCE-5133)
USB3H3 USB3 port (PCE-5133)
COM1 RS-232 (9-pin Box Header)
COM2 RS-232 (9-pin Box Header)
eSPI eSPI expansion pin header for COM module
SATA SATA0~1 SATA4~7 (PCE-5133) SATA4~7(PCE-5033)
SPI_CN1 CMOS flash jig pin-header
SPI1 CMOS ROM
DP1 Display port pin-header
DP2 Display port pin-header
JCMOS1 Clear CMOS
JME1 Clear ME
JFP1 + JFP2
Power Switch / Reset connector / External speaker / SATA HDD LED
connector
NVMe M.2 M.2 Key 2280 with PCIe Gen. 4
