PCE-5133/5033 User Manual 4
1.3.4 Graphics
Controller: Intel® UHD Graphics embedded in the processor.
Display memory: Shared memory is subject to OS (install 2 GB or above mem-
ory for basic system configuration).
VGA: 2048 x 1152 @60 MHz.
DVI-D: 1920 x 1200 @60 Hz.
Display port: 4096 x 2160 @60 MHz, 24bpp.
HDMI: 1920x1080 @60Hz
PCI express x16/x8 slot on the backplane: An external graphic card can be
installed in the PCIe x16 / x8 slot for high 2D/3D graphics capability.
1.3.5 Ethernet LAN
Supports single/dual 10/100/1000/2500 Mbps Ethernet port(s) via the dedicated
PCI Express p12-x1 bus which provides 500 MB/s data transmission rate.
Controller:
– LAN 1: I226LM(PCE-5133); I226V(PCE-5033)
– LAN 2: I226LM(PCE-5133); I226V(PCE-5033)
1.3.6 Industrial Features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels).
1.3.7 Mechanical and Environmental Specifications
Operating temperature: 0 ~ 60°C (32 ~ 140°F, depending on CPU and thermal
solution).
Storage temperature: -40 ~ 85°C (-40 ~ 185°F).
Humidity: 20 ~ 95% non-condensing.
Power supply voltage: +3.3 V, +5 V, +12 V, +5 V
SB.
Power requirements(Idle):
Note: Testing conditions:
CPU: Processor: Intel® i9-12900E
Memory: 2 DDR5 4800 32GB
Operating temperature: 0 ~ 60°C (depending on CPU)
Board size: 338 mm (L) x 122 mm (W) (13.31" x 4.8").
Board weight: 0.5 kg.
Voltage + 3.3V +5V +12V
Current 8.34A 4.13A 6.86A
