15 IDK-2115 User Manual
Chapter 3 LCD Signal Characteristics and Pin Assignments
3.3.2 Pin Assignment
Table 3.2: CN1, CN2 Output Connector
Pin No. Symbol Description
1 Output High Voltage
2 Output Low Voltage
Table 3.3: CN3 Input Connector
Pin No. Symbol Description
1 Vin Input Voltage 12V
2 Vin Input Voltage 12V
3 GND Ground
4 GND Ground
Table 3.4: CN4 Input Connector
Pin No. Symbol Description
1 Vin Input Voltage 12V
2 Vin Input Voltage 12V
3 GND Ground
4 GND Ground
5 Control
ON/OFF control
(ON=+1.5~5V OFF=0~0.8V)
6PWM
Brightness control
( 0V Min ~ 5V Max )
Table 3.5: CN5 Input Connector (Optional for VR Adjustment
Brightness)
Pin No. Symbol Description
1 Variable Resistor VR High Voltage
2 Variable Resistor VR
3 Variable Resistor VR Low Voltage
Table 3.6: CN6 Input Connector (Optional for Light Sensor Auto
Dimming)
Pin No. Symbol Description
1 Light sensor Sensor High Voltage
2 Light sensor Sensor Low Voltage
