IDK-2115 User Manual 16
3.4 Color Data Input Assignment
The brightness of each primary color (red, green and blue) is based on the 8-bit gray
scale data input for the color. The higher the binary input, the brighter the color. The
table below provides the assignment of color versus data input.
Note: 0:Low Level Voltage,1:High Level Voltage
Table 3.7: Color Data Input Assignment
Color
Data Signal
Red Green Blue
R7 R6 R5 R4 R3 R2 R1 R0 G7 G6 G5 G4 G3 G2 G1 G0 B7 B6 B5 B4 B3 B2 B1 B0
Basic Colors
Black 00000000 0 000 00000 0 000000
Red 11111111 0 000 00000 0 000000
Green 00000000 1 111 11110 0 000000
Blue 00000000 0 000 00001 1 111111
Cyan 00000000 1 111 11111 1 111111
Magenta11111111 0 000 00001 1 111111
Yellow 11111111 1 111 11110 0 000000
White 11111111 1 111 11111 1 111111
Gray
Scale
Of
Red
Red(0) /
Dark
00000000 0 000 00000 0 000000
Red(1) 00000001 0 000 00000 0 000000
Red(2) 00000010 0 000 00000 0 000000
: :::::::: : ::: ::::: : ::::::
: :::::::: : ::: ::::: : ::::::
Red
(253)
11111101 0 000 00000 0 000000
Red
(254)
11111110 0 000 00000 0 000000
Red
(255)
11111111 0 000 00000 0 000000
Gray
Scale
Of
Green
Green(0)
/ Dark
00000000 0 000 00000 0 000000
Green(1) 00000000 0 000 00010 0 000000
Green(2) 00000000 0 000 00100 0 000000
: :::::::: : ::: ::::: : ::::::
: :::::::: : ::: ::::: : ::::::
Green
(253)
00000000 1 111 11010 0 000000
Green
(254)
00000000 1 111 11100 0 000000
Green
(255)
00000000 1 111 11110 0 000000
Gray
Scale
Of
Blue
Blue(0) /
Dark
00000000 0 000 00000 0 000000
Blue(1) 00000000 0 000 00000 0 000001
Blue(2) 00000000 0 000 00000 0 000010
: :::::::: : ::: ::::: : ::::::
: :::::::: : ::: ::::: : ::::::
Blue
(253)
00000000 0 000 00001 1 111101
Blue
(254)
00000000 0 000
00001 1 111110
Blue
(255)
00000000 0 000 00001 1 111111
