13 ADAM-5000/TCP Series User Manual
Chapter 2 Selecting Your Hardware Components
The power consumption is:
5W * 3 + 2.9W * 4 + 1.25 * 6 + 1.8W * 5 + 1.2W * 5 + 1.5W * 4 = 55.1W
ADAM-5510
PC-Based Programmable Controller (With Battery
Backup)
1.0 W
ADAM-5510M
Enhanced PC-Based Programmable Controller
(With Battery Backup)
1.2 W
ADAM-5511 PC-Based Programmable Controller with Modbus 1.0 W
ADAM-5510E 8-clot PC-Based Programmable Controller 1.2W
ADAM-5510/TCP
Ethernet-enabled PC-Based Programmable Con-
troller
2.0W
ADAM-5510E/TCP
8-clot Ethernet-enabled PC-Based Programma-
ble Controller
2.0W
Main Units Description
Power
Consumption
ADAM-5013 3-Channel RTD Input Module 1.1 W
ADAM-5017
8-Channel Analog Input Module (mV, mA or High
Voltage)
1.25 W
ADAM-5017H
8-Channel High speed Analog Input Module (mV,
mA or High Voltage)
2.2 W
ADAM-5017UH
8-Channel Ultra High speed Analog Input Module
(mV, mA or High Voltage)
2.2 W
ADAM-5018
7-Channel Thermocouple Input Module (mV, V,
mA, Thermocopule)
0.63 W
ADAM-5024 4-Channel Analog Output Module (V, mA) 2.9 W
ADAM-5050 16-Channel Universal DIO 1.2 W
ADAM-5051 16-Channel Digital Input Module 0.53 W
ADAM-5051D 16-Channel Digital Input w/LED Module 0.84 W
ADAM-5056S 16-Channel Isolated Digital Input w/LED Module 0.8 W
ADAM-5056SO 16-Channel Digital Input w/LED Module 0.84 W
ADAM-5052 8-Channel Isolated DI 0.27W
ADAM-5055S 16-Channel Isolated DIO w/LED Module 0.68 W
ADAM-5056 16-Channel Digital Output Module 0.53 W
ADAM-5056D 16-Channel Digital Output w/LED Module 0.84 W
ADAM-5056S 16-Channel Isolated Digital Output w/LED Module 0.6 W
ADAM-5060
6-Channel Relay Output Module ( 2 of Form A, 4
of Form C)
1.8 W
ADAM-5068 8-Channel Relay Output Module ( 8 of Form A) 1.8 W
ADAM-5080 4-Channel Counter/ Frequency Input Module 1.5 W
ADAM-5090 4-Port RS232 Module 0.6 W
Calculate the Summary of the whole system’s power consumption.
For example, if there are these following items in your system.
ADAM-5000/TCP * 3 & ADAM-5024 * 4 & ADAM-5017 * 6 &
ADAM-5068 * 5 & ADAM-5050 * 5 & ADAM-5080 * 4
ƒ
Select a suitable power supply from Table 2.4 or other comparable power
resources for system operation.
Table 2.3: Power Consumption of ADAM-5000 series
