ADAM-5000/TCP Series User Manual 12
2.2 Selecting Power Supply
ADAM-5000/TCP series system works under unregulated power source between
+10 and +30 VDC. When you arrange different I/O modules on ADAM-5000/TCP’s
back plant, it may require comparable power supply. Use the following steps as
guidelines for selecting a power supply for your ADAM-5000/TCP system.
Refer to Table 2.3 to check the power consumption of ADAM-5000/TCP Series
main unit and each I/O module.
Module ADAM-5060 ADAM-5068 ADAM-5080 ADAM-5090
Resolution - - - -
Analog
Input
Input
Channel
- - - -
Sampling Rate - - - -
Voltage
Input
- - - -
Current
Input
- - - -
Direct
Sensor Input
- - - -
Analog
Output
Resolution - - - -
Voltage Output - - - -
Current
Output
- - - -
Digital
Input
and
Digital
Output
Digital
Input
Channels
- - - -
Digital
Output
Channels
6 relay
(2 form A/ 4 form C)
8 relay
(8 form A)
- -
Counter
(32-bit)
Channels - - 4 -
Input
Frequency
- -
5000 Hz
(max)
-
Mode - -
Frequency,
Up/Down
Counter,
Bi-direction
Counter
-
COMM
Channels - - - 4
Type - - - RS-232
Isolation - - 1000 VRMS -
Table 2.3: Power Consumption of ADAM-5000 series
Main Units Description
Power
Consumption
ADAM-5000/485
Distributed Data Acquisition and Control System
based on RS-485
1.0 W
ADAM-5000E
Distributed Data Acquisition and Control System
based on RS-485
4.0 W
ADAM-5000/TCP
Distributed Data Acquisition and Control System
based on Ethernet
5.0 W
