Vizi Spot 5R System Menu

ADDRESS MENU -

A001 - A511 - This is where you set the DMX address of the unit.

TEST MENU -

T-01 - T-XX - Tests the functions of each channel.

Note: Some channels cannot be tested.

PLAY MENU -

AUTO - This is a precaution mode in case the DMX signal is lost.

There are four settings to choose from:

• “Clos” - The xture will close the lens shutters.

• “Hold” - This is the default setting, which in case the signal is

lost the xture will “hold” at the last setting.

• “Auto” - The xture will go into Auto mode and run a pre-pro-

grammed show.

• “Audi” - The xture will go into Sound Active mode.

LAMP MENU -

ON/OFF - Manually switches the lamp “On” or “O”.

RESE (RESET) MENU -

ALL - Resets all motors.

SCAN - Resets the pan/tilt motors.

COLR (Color) - Resets the color wheel motor.

GOBO - Resets the gobo wheel motor.

SHTR (Shutter) - Resets the shutter and dimmer motors.

OTHR - Resets all other motors.

TIME MENU -

LIFE - Displays the total xture running time.

LAMP - Displays the lamp running time.

CLMP - Clears the lamp running time.

RPAN MENU -

ON/OFF - Reverses the pan.

RTLT MENU -

ON/OFF - Reverses the tilt.

FINE MENU -

ON/OFF - Switch between 8bit (coarse) and 16bit (ne) pan & tilt

movement. This also switches the DMX channel mode between

11 channel (8 bit) and 13 channel (16 bit) DMX mode.

DEGR MENU -

540/360 - Switch the degree of the Pan between 360 and 540.

MIC MENU -

M-01-M-70 - With this function you can make the internal mic

more or less sensitive to sound.

DISPLAY MENU -

VALU (DMX-512 Value) - Display the DMX-512 value of each

channel.

D ON - Turns digital display o after 2 minutes.

FLIP - “Flips” the digital display 180º.

LOCK - When activated the buttons will lock automatically after

15 seconds.

SPEC MENU -

LAAU - On/O Automatically switches on lamp when power is

applied.

RDMX - On/O With this function you are able to change the

DMX address via external controller. See pages 29-30.

DLOF (Lamp Adjustment) - With this function you can adjust the

lamp via the control board. In this mode, the device will not

react to any control signal.

DLAY - With this function you can put the lamp on a delay time.

Vizi Spot 5R System Menu

American DJ® - www.americandj.com - Vizi Spot 5R Instruction Manual Page 18American DJ® - www.americandj.com - Vizi Spot 5R Instruction Manual Page 17
