American DJ® - www.americandj.com - Vizi Spot 5R Instruction Manual Page 16American DJ® - www.americandj.com - Vizi Spot 5R Instruction Manual Page 15

5-Pin XLR DMX Connectors.

Some manufactures use 5-pin DMX-

512 data cables for DATA transmission in place of 3-pin. 5-pin DMX

xtures may be implemented in a 3-pin DMX line. When inserting stan-

dard 5-pin data cables in to a 3-pin line a cable adaptor must be used,

these adaptors are readily available at most electric stores. The chart

below details a proper cable conversion.

Conductor 5-Pin XLR Male (In)3-Pin XLR Female (Out)

Pin 1

Pin 5 - Do Not Use

Pin 4 - Do Not Use

Pin 3

Pin 2

Pin 1

Pin 3

Pin 2

Not Used

Data True (+ signal)

Data Compliment (- signal)

Ground/Shield

3-Pin XLR to 5-Pin XLR Conversion

Vizi Spot 5R DMX Set Up Vizi Spot 5R System Menu

VALU A001~A511 (AXXX) DMX address setting

SLAV ON/OFF (SLAV) Slave setting

ADDR

EBOC

ON/OFF

Change DMX address via

external controller

ALON (AU-A) Automatic Run in Stand Alone

AUTO

MAST (AU-M) Automatic Run as Master

ALON (SO-A)

Sound-controlled Run in Stand

Alone

RUN

SOUN

MAST (SO-M) Sound-controlled Run as Master

VALU D–XX D-00 (DXXX)

Display the DMX 512 value of

each channel

RDIS ON/OFF Reverse display

CLDI ON/OFF Shut off LED display

0 MODE

DISP

LOCK ON/

OFF Key Lock

OPEN ON/OFF Lamp on/off

LAAU ON/OFF Lamp automated on with power

ONLI ON/OFF Lamp on/off via controller

1 LAMP

DELA D–XX

D-05 Delay lamp on

RPAN ON/OFF Pan Reverse

RTIL ON/OFF Tilt Reverse

16BI ON/OFF Switch 16 bit/8 bit

DEGR 360/540 Pan degree select

MIC M-XX M-70 Mic sensitivity

AUTO Clos/Hold/Auto/Audi No DMX Status

FANS AUTO/HIGH/LOW Fan’s mode select

REST Reset

LODA ON/OFF Restore factory settings

HIBE OFF/1-99M 15M Stand by mode

2 SET

VER V-1.0~V-9.9 Software version

LADJ ON/OFF Lamp adjustment

TEST T–01~T–XX Test function of each channel

CODE CXXX Fixture code *code is “C050”

3 ADJU

WHEL

CH01~CHXX XXXX(-128~127) Motor Fix

MATI 0000~9999(hours) Fixture running time

LATI 0000~9999(hours) Lamp running time

CLMT ON/OFF (Password is 838) Clear fixture time

4 TIME

CLLT ON/

OFF Clear lamp time

SEPR

AUTO

IP01~IP08

Select program to be edit

STEP S–01 ~S–48 Steps of Program Run

REC. RE.XX Auto Save Scene

C–01~C–XX XXX(000~255) Edit the channels of each scene

TIME XXXX(000.2s~199.8s) Time for each scene

5 EDIT

SC01

~ SC48

CNIN ON/

OFF Edit program via controller
