American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 18American DJ® - www.americandj.com - Vizi Scan LED PRO Instruction Manual Page 17

Vizi Scan LED PRO System Menu

CLMP - Clears the xture running time.

RPAN (REVERSE PAN) MENU -

ON/OFF - When “On” is chosen it will reverse the pan.

RTILT (REVERSE TILT) MENU -

ON/OFF - When “On” is chosen it will reverse the tilt.

FINE MENU -

ON/OFF - Switch between 8bit (coarse) and 16bit (ne) pan & tilt

movement. This also switches the DMX channel mode between

12 channel (8 bit) and 14 channel (16 bit) DMX mode.

MIC MENU -

M-01-M-70 - With this function you can make the internal mic

more or less sensitive to sound.

DISPLAY MENU -

VALU (DMX-512 Value) - Display the DMX-512 value of each

channel.

D ON (Display On) - Turns digital display on and off.

FLIP - “Flips” the digital display 180º.

LOCK - When activated the buttons will lock automatically. See

page 26 for more information.

SPEC MENU -

RDMX - On/Off With this function you are able to change the

DMX address via external controller. See pages 25-26.

SPOT - This provides a spot beam for better lamp optimization.

DFSE - This will reset the unit to the default settings.

FANS - Select the fan running mode.

HIBE - This feature will automatically shut down the lamp and

stepping motors. Please see pages 28-29.

VER (Version) - Software version 2.2

Vizi Scan LED PRO System Menu

ADJU - Calibration functions

EDIT MENU -

SEPR (AUTO IP01 - IP07) - Lets you edit any of the 7 internal

programs.

STEP (Step) - Steps to be used in Edit Programming. See ediit

program. See pages 33-35.

SCO1 - SC48 (Scene 01 - Scene 48) - These are the scene slots

that you write your programs into. See edit program, pages

33-35.

TIME (Time) - Time for each scene. See pages 33-35.

CEDT - Edit program using a external controller. See pages

33-35.

C-01 - C-30 (Channel 1 - Channel 30) - The channels of each

scene that can be edited. See pages 33-35.
