ADDRESS MENU -

AOO1 - A511 (Value) - This is where you set the DMX address of

the unit.

TEST MENU -

T-01 - T-XX (Test) - Tests the functions of each channel. Note:

Some channels cannot be tested.

PLAY MENU -

RUN - Runs the unit as a “master” or in a stand alone mode. The

unit will run a internal program mode.

AUDI (Audio) - Runs the unit as a “master” or in a stand alone,

sound active mode.

AUTO - This is a precaution mode in case the DMX signal is lost.

There are four settings to choose from:

• “Hold” - This is the default setting, which in case the signal is

lost the xute will “hold” at the last setting.

• “Close” - The xture will return to its “home” standing.

• “Auto” - The xture will go into Auto mode and run a pre-pro-

grammed show.

• “Audi” - The xture will go into Sound Active mode.

RESE (RESET) MENU -

ALL - Resets all the motors in the unit.

SCAN - Resets the motors that control pan/tilt.

COLR (Color) - Resets the color motors.

GOBO - Resets the gobo motors.

OTHR - Resets all other motors.

TIME MENU -

LIFE - Displays the xtures total running time.

Vizi Scan LED PRO System Menu

Default setting shaded.

ADDR

AXXX A001

Indicate the staring DMX address

A001 also is the setting for slave

TEST

T-01~T-XX

Automatically test the function

RUN

MSTR/ALON

Runs fixture as “master” or “alone” for

auto

AUDI

MSTR/ALON

Runs fixture as “master” or “alone” for

audio

PLAY

AUTO

Clos/Hold/Auto/Audi

No DMX Status

ALL

Reset all motors and returns fixture to

home

SCAN

Reset only motors for pan/tilt

COLR

Reset only motors for colors

GOBO

Reset only motors for gobo and rotation

RESE

OTHR

Reset other motors

LIFE

0000~9999

Displays the total fixture running time

TIME

CLMP

Clear lamp running time

RPAN

ON/OFF

Reverses the pan movements

RTLT

ON/OFF

Reverses the tilt movements

FINE

ON/OFF

Switch 16 bit/8 bit

MIC

M-XX M-70

Mic sensitivity

VALU

D–XX D-00 (DXXX)

Display the DMX512 value of each

channel

D ON

ON/OFF

Display turn off after 2mins

FLIP

ON/OFF

This function will reverse the display

180

DISP

LOCK

ON/OFF

Key lock

RDMX

ON/OFF

Change DMX address via external

controller

SPOT

ON/OFF

Lamp optimization

DFSE

ON/OFF

Resets all the fixture functions to

default

FANS

AUTO/HIGH/LOW

Fan’s mode select

HIbE

OFF/1-99M 15M

Stand by mode

VER

V1.0~V9.9

Software version

CODE

CXXX

Fixture code *code is “C050”

SPEC

ADJU

CH01~CHXX

XXXX(-128~127)

Motor Fix

SEPR

AUTO

IP01~IP07

Select program to be edit

STEP

S–01 ~S–48

Set the amount of your

program

C–01~C–XX

XXX(0~255)

Edit the channels of each

scene

TIME

T XXX(001~999)

Time for each scene

SCXX

CEDT

ON/OFF

Edit program via controller

REC.

RE.XX

Auto Save

EDIT

RUN

ON/OFF

Program test

Vizi Scan LED PRO System Menu
