ADJ Products, LLC ! ww.adj.com ! VIZI CMY 16RX User Instructions Page 28
View DMX Value: This function will allow you to see the DMX value of each DMX
channel that is currently being used at the time.
1. Access the main menu, and press the UP or DOWN buttons so that
“DMX
Settings” is highlighted, then press ENTER.
2. Press the UP or DOWN buttons until “DMX Value” is displayed, and press
ENTER.
3. A DMX Channel will be displayed. Example: Prism, Color Wheel, Gobo Wheel,
etc. Press ENTER when you find the DMX channel that you would like to check.
When you press ENTER the DMX value of that channel will displayed.
4. Press the MENU button to exit and return to the main menu.
FIXTURE SETTING
Pan Invert: With this function, you can reverse the Pan movement.
1. Access the main menu, and press the UP or DOWN buttons so that
“
Fixtur
e
Settings” is highlighted, then press ENTER.
2. Press the UP or DOWN buttons until “Pan Invert” is displayed, and press
ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”. Selecting
“YES” will activate pan invert, “NO” will deactivate the function.
4. Press ENTER to confirm your selection or press the MENU button to return to the
main menu.
Tilt Invert: With this function, you can reverse the Tilt movement.
1. Access the main menu, and press the UP or DOWN buttons so that
“
Fixtur
e
Settings” is highlighted, then press ENTER.
2. Press the UP or DOWN buttons until “Tilt Invert” is displayed, and press
ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”. Selecting
“YES” will activate tilt invert, “NO” will deactivate the function.
4. Press ENTER to confirm your selection or press the MENU button to return to
the main menu.
P/T Feedback: With this function, you have the pan and tilts position feedback while out
of step or not feedback while out of step.
1. Access the main menu, and press the UP or DOWN buttons so that
“
Fixtur
e
Settings” is highlighted, then press ENTER.
2. Press the UP or DOWN buttons until “P/T Feedback” is displayed, and press
ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”. Selecting
“YES” will activate feedback, “NO” will deactivate the function.
4. Press ENTER to confirm your selection or press the MENU button to return to
the main menu.
VIZI CMY 16RX
System Menu
