ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 28
ADJ Products, LLC - www.adj.com - Focus Spot Two Instruction Manual Page 29
Focus Spot Two Master-Slave Set Up
Master-Slave Operation This function will allow you to link up to 16
units together and operate without a controller. The units will be sound
activated. In Master-Slave operation one unit will act as the controlling
unit and the others will react to the controlling units programs. Any unit
can act as a Master or as a Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the Master unit press the MENU button until “Slave Mode” is
displayed, and press ENTER. Use the UP and DOWN buttons to
scroll to the “Master” setting and press ENTER.
3. After setting the Master unit to the master setting find and set
your desired operating mode.
4. On the slave units press the MENU button until “Slave Mode” is
displayed, and press ENTER. Choose either “Slave 1” or “Slave
2” and press ENTER.
5. The slave units will now follow the Master unit.
With this feature you can connect the xtures to one another
using the PowerCon input and output sockets. The quantity that
can be connected is 14 xtures maximum @ 120V and 26 xtures
maximum @ 230V. After you have reached the maximum amount
of xtures you will need to use a new power outlet. They must be
the same xtures. DO NOT mix xtures.
Focus Spot Two Power Cord Daisy Chain
The UC IR (sold separately) infrared remote gives you control of
various functions (See below). To control the fixture you must aim the
remote at the front of the fixture and be no more than 30 feet away.
The Airstream IR (sold separately) remote transmitter plugs into
the headphone jack of your iOS phone or tablet. To control your IR
fixture you must raise the volume to the maximum on your iOS phone
or tablet and aim the transmitter at the fixture sensor and be no more
than 15 feet away. After you have purchased the Airstream IR trans-
mitters, the app is a free download from the app store for your iOS
phone or tablet. The app comes with 3 pages of control depending
on the fixture you are using. Please see below for IR functions. This
unit works with App page 1.
STAND BY - Pressing this button will blackout the fixture.
FULL ON - Hold this button down to fully light up the unit. When you
let the button go, the unit will return to its previous state.
FADE/GOBO - Press this button once to access gobo wheel. Use
the number buttons to find your desired gobo.
“DIMMER +” and “DIMMER -” - Use these buttons to adjust the out-
put intensity in Color mode.
STROBE - This button will activate the strobe effect. Press and hold
this button to activate strobing and release the button to stop strob-
ing.
COLOR - Press this button to access the color wheel. Use the num-
ber buttons to select your desired color. Adjust the output intensity
using the “DIMMER +” and “DIMMER -” buttons.
1-9 - In color mode and gobo mode, these buttons will allow you to
select a desired color or gobo. In show mode buttons 1-4 will let you
select your desired show.
SOUND ON & OFF - These buttons activate and deactivate the
sound active mode.
SHOW - This activates the show mode. Use buttons 1-4 to select
your desired show.
Focus Spot Two Remote Operation
Focus Spot Two Manual Focus
The focus can be adjusted under DMX control. It can also be manu-
ally focused using the focus wheel located on the bottom front of the
moving head. Rotate the focus wheel back and forth until you get your
perfect focus. This wheel can be used in conjunction with the focus
channel in DMX mode as well.
