Dimmer Manager software
Instruction Manual - page 45
Issue: 004
Lighting Technologies
Glossary
ADN Advanced Dimmer Network; name for the network which establishes
serial bi-directional communication between dimmer units, and
between NETPORT XT and dimmer units. The name is also used for
the proprietary protocol. ADN is based on EIA-485 and meets the
DMX512/1990 standard. ADN uses the second data pair in the DMX
cable, or a dedicated data cable. ADN is half-duplex (bi-directional
communication over one data pair).
Back-up look see (local) memories
Cue see (local) memories
Curve see dimmer law
Custom law user-defined dimmer law, which is stored in the dimmer unit. The
Dimmer Manager PC stores a library of standard and custom laws.
Dim file file generated by Dimmer Manager; includes equipment (dimmer units,
NETPORT XT); all dimmer settings (patch, laws, local memories);
system organisation (groups, names); alarm settings,…
Dimmer one of the dimmer channels in a ‘dimmer unit’; a MEMOPACK 30
- 12 x 3 kW is a dimmer unit with 12 dimmers
Dimmer curve see dimmer law
Dimmer law the relation between the control level (DMX) and dimmer output
voltage
Dimmer manager a software programme; filename dimmer.exe
Dimmer manager PC the PC which runs the Dimmer Manager programme
Dimmer module a EURODIM module; can hold one or two dimmers
Dimmer name user-defined alpha-numerical text attached to a dimmer; can be
different for every show
Dimmer unit a EURORACK 60, a EURODIM 3, a MEMOPACK 30,...
DMX512-A the future release of the DMX standard; successor to
DMX512/1990
FTP cable foiled twisted pair; a type of Ethernet cable which is also suitable
for the distribution of DMX and ADN signals
House patch preferred DMX patch; stored in the dimmer unit
law file file describing a dimmer law
Linguist a programme for the translation of Dimmer Manager to additional
languages
Local Control when you use the local keys / display / menu of the dimmer unit
NETBUS a portable remote dimmer control unit, which communicates with
ADB digital dimmers over the ADN network
