www.acopower.com
11
Refer to the below the diagram:
2.5 Mounting
WARNING: Do not reverse the polarity of the batteries. Reverse polarity will damage
the charge controller permanently. Damage caused by reverse polarity, is not covered by
warranty.
WARNING: Risk of explosion! Never install the controller in a sealed enclose with
flooded batteries! Do not install in a confined area where battery gas can accumulate.
WARNING: Risk of electric shock! The solar array high voltage can cause serious
shock or injury. Make use of fuses/breaker or cover the entire solar array, prior to performing
any work on change controller.
CAUTION：
The controller requires at least 150mm of clearance above and below for
proper air flow. Ventilation is highly recommended if mounted in an enclosure.
Installation steps:
Step 1: Determination of Installation Location and Heat-dissipation Space
Determination of installation location: The controller shall be installed in a place with sufficient
air flow through the radiators of the controller and a minimum clearance of 150 mm from the
upper and lower edges of the controller to ensure natural thermal convection. Please see
below Figure
CAUTION: If the controller is to be installed in an enclosed box, it is important to
ensure reliable heat dissipation through the box.
