12
Step 2：
Remove the terminal protective cover
Step3：
Connect the batteryᬚ(Left) and PVᬛ(Right)
NOTE: Disconnect the system in the reverse order.
WARNING: Do not reverse the polarity of the batteries. Reverse polarity will damage the
charge controller permanently. Damage caused by reverse polarity, is not covered by warranty.
CAUTION: While wiring the controller do not turn on the breaker or fuse and make sure
that the leads of "+" and "-" poles are connected correctly.
CAUTION: A fuse which current is 1.25 to 2 times the rated current of the controller
must be installed on the battery side with a distance from the battery not greater than 150 mm.
CAUTION: If an inverter is to be connected to the system, connect the inverter directly
to the battery.
