Chapter 3 Hardware Panels

XGS1935 Series User’s Guide

46

Table 8 LED Descriptions

LED COLOR STATUS DESCRIPTION

10/100/1000Base-T Ports

LNK/ACT

1 – 24 (XGS1935-28)

1 – 48 (XGS1935-52)

Green (Right) On The link to a 1000 Mbps Ethernet network is up.

Blinking The Switch is transmitting or receiving to or from a 1000 Mbps

Ethernet network.

Amber (Left) On The link to a 10 Mbps or a 100 Mbps Ethernet network is up.

Blinking The Switch is transmitting or receiving to or from a 10 Mbps or

a 100 Mbps Ethernet network.

Off The link to an Ethernet network is down.

PoE 10/100/1000Base-T Ports

LNK/ACT (Left)

1 – 24 (XGS1935-28HP)

1 – 48 (XGS1935-52HP)

Green On The link to a 1000 Mbps Ethernet network is up.

Blinking The Switch is transmitting or receiving to or from a 1000 Mbps

Ethernet network.

Amber On The link to a 10 Mbps or a 100 Mbps Ethernet network is up.

Blinking The Switch is transmitting or receiving to or from a 10 Mbps or

a 100 Mbps Ethernet network.

Off The link to an Ethernet network is down.

PoE (Right)

1 – 24 (XGS1935-28HP)

1 – 48 (XGS1935-52HP)

Green On Power supplied to all PoE Ethernet ports meets the IEEE

802.3at standard.

Amber On Power supplied to all PoE Ethernet ports meets the IEEE

802.3af standard.

Off There is no power supplied.

1G/10G SFP+ Slots

LNK/ACT

25 – 28 (XGS1935-28

and XGS1935-28HP)

49 – 52 (XGS1935-52

and XGS1935-52HP)

Green On The port has a successful 1000 Mbps connection.

Blinking The port is transmitting or receiving data at 1000 Mbps.

Blue On The port has a successful 10 Gbps connection.

Blinking The port is transmitting or receiving data at 10 Gbps.

Off This link is disconnected.
