22
ZOOM 506 II BASS
ZOOM 506 II BASS
23
PATCH LEVEL
PATCH LEVEL
Adjusts the overall volume of the patch. A value of 25 corresponds to unity
gain (input level and output level are equal).
1
3
0
COMP LIMIT WAH
COMP module basic parameters
COMPRESSOR (Compressor)
This effect type attenuates high-level signal components and boosts low-level signal
components, thereby keeping the overall signal level within a certain range. The
effect prolongs sustain and makes the sound more uniform. Higher setting values
result in stronger compression.
LIMITER (Limiter)
This effect type attenuates peak levels and prevents overload of the next
module. Higher setting values result in stronger limiter action.
FAT WAH (Fat Wah)
This effect type applies auto wah which is dependent on playing intensity. It is
characterized by a fat sound. Higher right-digit setting values result in higher
input sensitivity for the auto wah effect.
PEDAL FAT WAH (Pedal Fat Wah)
This effect type allows using an expression pedal (FP01/FP02)
connected to the CONTROL IN jack for pedal wah. The expression pedal
then controls the frequency that is emphasized by the fat wah effect.
This module comprises the compressor, limiter, auto wah,
and other effect types. Use the [+]/[-] keys to select the
effect type and adjust the effect intensity.
C
1
C
9
L
1
L
9
F
1
F
8
F
P
TIME
LEVEL
TIME
LEVEL
TIME
LEVEL
TIME
LEVEL
Original sound
Compressor
Limiter
Original sound
RESONANT WAH (Resonant Wah)
This effect type applies auto wah to a narrow frequency band, resulting in a
special effect. Higher right-digit setting values result in higher input sensitivity
for the auto wah effect.
PEDAL RESONANT WAH (Pedal Resonant Wah)
This effect type allows using an expression pedal (FP01/FP02)
connected to the CONTROL IN jack to control the frequency that is emphasized
by the resonant wah effect.
OFF (Off)
Turns the COMP module off.
r
1
r
8
r
P
o
F
DIST
DIST module basic parameters
BANDPASS ENH (Bandpass Enhancer)
Enhancer using a bandpass filter. Makes the sound more distinct.
HIPASS ENH (High-Pass Enhancer)
Enhancer using a high-pass filter, resulting in a different sonic character from the
bandpass enhancer.
CLEAN 1 (Clean 1: clean type effect)
Clean sound with flat characteristics.
CLEAN 2 (Clean 2: clean type effect)
High-class clean sound with attenuated midrange.
RICH (Rich: clean type effect)
Rich clean sound with emphasized bass range.
In addition to five distortion type effects and five clean
type effects, this module also comprises two enhancer
effect types. Use the [+]/[-] keys to select the effect type.
FAT (Fat: clean type effect)
Clean sound with emphasized midrange.
SLAP (Slap: clean type effect)
Clean sound suitable for the slap playing style.
EDGE (Edge: distortion effect)
Treble-rich drive sound.
b
E
H
E
C
1
C
2
r
C
F
t
S
L
E
G
Effect Types and Parameters
Effect Types and Parameters
