4.6 Stopping the Cleaner
and Removing from the Pool
The automated Lift System makes removing the cleaner
from the pool simple. The Lift System will move the
cleaner toward the edge of the pool then drive it to the
surface for removal.
1. At the end of the cleaning cycle, or at any time
during a cleaning cycle, press to begin the
automated lift procedure.
Press and hold the Lift System button to turn
cleaner to the left. Cleaner will keep rotating left.
Once the cleaner is oriented towards the wall of
your choice, release the button.
Press and release the Lift System button and the
cleaner will drive up the wall and to the waterline
and wait to be retrieved.
The screen displays when the Lift
System is in operation.
NOTE: Tostoptheliftprocedureatanytime,press .
2. When the cleaner is within arm's reach, use the
handle to remove from the water (Figures 18,
19). Never lift the cleaner out of the pool by the
oatingcable.
1
2
Figure 21. Remove Cleaner From Pool with Handle
3
Figure 22. Keep Cleaner Vertical to Drain Water
4.7 Operating the Cleaner with the
Remote Control (VX55 4WD only)
The VX55 4WD robotic cleaner comes with a handheld
remote control stored on the cleaner caddy next to the
control box. The remote control is factory-synchronized
to your cleaner's control box.
ON/OFF
button
Lift System
button
Figure 20. VX55 4WD Remote Control
• To turn on the remote control:
Press (see Figure 20) and hold for 3 seconds.
The display shows to indicate the
cleaner is now operating in remote control mode.
• To pilot the cleaner, point the device toward the
cleaner in the water and move directionally as shown
in Figure 21.
Backward
Turn Left
Stop
Turn Right
Forward
Figure 21. Remote Control Directional Commands
H0516700_REV A
12
