❶ Specicaons

1.1 I Descripon

A RE/U electric heater

B Ø63 connector (x2)

C Ø50 connector (x2)

D Joint (x2)

1.2 I Technical specicaons

RE/U electric heater 12M 15M 15T 18T 21T 24T

Operang

temperature

Wa-

ter

2 to 40 °C

Power supply

/

220-240V/1N~/50-

60Hz

380-400V/3P~/50-60Hz

Heang element

rang*

kW 6 + 6 6 + 9 6 + 9 9 + 9 9 + 12 12 + 12

Current input** A 53 66 22 26 31 35

Power cord size*** mm

2

3 x 16 5 x 6 5 x 10

Minimum ow m

3

/h 5

Maximum ow m

3

/h 22

Test pressure

Bar 4

Pa 400000

Service pressure

Bar 2

Pa 200000

Hydraulic connecons / PVC Ø50 (internal) or Ø63 (external)

Protecon rang / IPX2

Weight kg 12

* With manufacturer's tolerance ± 5%

** RMS voltage tolerance + 6 - 10%.

*** Values provided for informaon purposes for a maximum length of 20 metres (calculaon base: NFC 15-100), must be checked and adapted to the

installaon condions and standards of the installaon country.
