1.2 I Hydraulic connecons
• The device will be connected with a Ø50 PVC pipe, using the connectors supplied (see § "5.1 I Descripon"), to the
pool's ltraon circuit, aer the lter and before the water treatment system.
• Respect the direcon of hydraulic connecon.
• A by-pass must be installed to make it easier to work on the appliance.
: Water inlet valve
: By-pass valve
: Water outlet valve
: Water inlet adjustment valve
(oponal)
: Water outlet adjustment valve
(oponal)
: Water treatment system
• To evacuate the condensates, t an internal Ø18 pipe under the appliance base.
Locaon for connecng the condensate drainage line (appliance as seen from below)
Tip: condensate drainage
Cauon, several litres of water can be drained from your appliance each day. We strongly recommend
connecng the drain to a suitable water drainage system.
