38
❸ Maintenance
3.1 I Winterising
• Even though the appliance can be used year round, if it will not be used for the winter months,
a suitable winterising procedure must be implemented to prevent damage to the condenser.
Damage caused by improper winterising of the appliance when not in use is not covered by
the warranty.
• To prevent condensaon from damaging the appliance: cover the appliance with the
winterising cover supplied (do not hermecally-seal the appliance inside a cover).
• Switch o the appliance by pressing and holding for 5 seconds and disconnect the power supply,
• Open valve B (see § "1.2 I Hydraulic connecons"),
• Close valves A and C and open valves D and E (if present, see § "1.2 I Hydraulic connecons"),
• Make sure that there is no water circulang in the heat pump,
• Drain the water from the condenser (risk of freezing) by unscrewing the two water inlet and outlet connectors on the
back of the heat pump,
• In the case of full winterising for the pool (complete shutdown of the ltraon system, bleed the ltraon circuit
or even pool drainage): re-t the two connectors by one turn to prevent any foreign bodies from geng into the
condenser,
• In the case of winterising the heat pump only (shutdown of the heang only, the ltraon keeps running): do not re-t
the connectors; instead add 2 caps (not provided) on the condenser's water inlet and outlet.
• We recommend that you put the aired winterising micro cover (provided) over the heat pump.
3.2 I Maintenance
• Before any maintenance work on the appliance, you must cut the electricity supply as there is
a risk of electric shock which may cause material damage, serious injury or even death.
• It is recommended that the appliance undergo general servicing at least on a yearly basis to
ensure its proper operaon, maintain performance levels and prevent any possible failures.
These operaons are carried out at the user's expense, by a qualied technician.
3.2.1 Safety instrucons concerning appliances containing R32 refrigerant (PM40 MD1, MD2, MD3, MD4,
MD5, MD7, TD7, TD8 & MD12 models)
Area check
• Before starng work on systems containing ammable refrigerants, safety checks must be carried out to guarantee a
minimal ignion risk.
Work procedure
• The work must be carried out according to a controlled procedure in order to reduce the risks of releasing a ammable
gas or vapour while working.
General work area
• All maintenance sta and other personnel working in the surrounding area must be made aware of the work carried
out. Work conducted in enclosed areas must be avoided.
Check for the presence of refrigerant
• The area must be analysed using a suitable refrigerant detector before and during work so that the technician is
informed of the presence of a potenally toxic or ammable atmosphere. Check that the leak detecon equipment
used is suitable for use with all refrigerants concerned, i.e. that it does not cause a spark, is correctly isolated or is
enrely safe.
Check for the presence of a re exnguisher
• If work must be carried out on the cooling equipment or any part associated therewith at a certain temperature,
suitable re exnguishing means must be within reach. Place a dry chemical re exnguisher or CO
2
re exnguisher
near the work area.
No source of ignion
• No person carrying out work on a cooling system involving exposing the piping may use any ignion source, which
could create a re or explosion risk. All possible ignion sources, in parcular cigarees, must not enter within a
sucient perimeter of the installaon, repair, removal or disposal site, in the event that refrigerant could be released
into the surrounding space. Before starng the work, the area around the equipment must be examined to check for
all re or ignion risks. "No smoking" signs must be displayed.
Area venlaon
• Before accessing the unit in any manner whatsoever with the intenon of performing any maintenance task, check
that the area is open and well-venlated. Suitable venlaon must be provided throughout the maintenance task to
allow any refrigerant that could be released into the atmosphere to be safely dispersed.
EN
