MagnaPool™ | Installation Manual
1. Remove the lower housing and cover to
expose the connection bar.
2. Run the supplied low voltage 2 core wire
through the rubber grommet from the relay
switch box into the terminal bar marked
‘AUX 2’.
3. Push the red pin connector into the relay
switch.
4. Use cable ties to hold in place if necessary,
then replace the cover/s.
5. Plug the relay switch box into any
available 240V GPO.
6. Plug the light transformer directly into the
socket located in the switch box. This will now
control the light directly from the chlorinator.
<-FILTER PUMP
-AUX/LIGHTS
-PROGRAMMING
-LOW MODE
-SLAVE MODE
-REVERSING
-HELP MENU
-LANGUAGE
MAIN MENU
<
-BACKWASH
-SINGLE SPEED
-VARIABLE SPEED
FILTER PUMP
<
PLUGD TO DEVICE?
-YES
-NO
VARIABLE SPEED
<
VARIABLE SPEED
-SPEEDS
-MIN/MAX
-PRIMING
-PROGRAMMING
<
VSP SPEEDS
-RPM 1 1000
-RPM 2 1500
-RPM 3 2000
-RPM 4 2850
-QUICK 3450
8.1.5 Quick Clean
Quick Clean is a backwash mode is used to quickly
start/stop the filter pump (single- or variable-speed
pump) in order to backwash the filter.
For variable speed pumps, the backwash RPM is
set under “Quick”.
1. Select YES to activate ltration.
2. Select NO to stop ltration.
For safety reasons, the chlorination is stopped
during the backwash mode. To avoid emptying the
pool, the backwash mode automatically stops after
5 minutes. The variable speed pump RPM is by
default set at 3450 rpm (max speed). This can be
changed in the priming menu.
8.2 Aux/Lights
The chlorinator is capable of controlling devices in
addition to the filter pump. The equipment must be
connected to the chlorinator using the appropriate
auxiliary line:
Aux 1: for equipment connected to the high voltage
supply (230 V) (not applicable for Australia).
Aux 2: for equipment connected to the low voltage
supply (12/24 V).
The following functions are available in the
AUX/LIGHTS menu for auxiliaries 1 and 2:
● Turn the lights or aux equipment on/off
● Program a timer (See section 8.7.6 for details)
NOTE: For Australian chlorinator to control the light
transformer, an additional switching box is
required. Please contact your local pool care
professional for this relay box, item code
WW000222.
