Indicator lights
Descripon Steady Flashing O
"HEATING" mode
Operang in "HEATING"
mode
/ Disabled
"COOLING" mode
Operang in
"COOLING" mode
/ Disabled
"HEATING & COOLING"
mode
Operang in "HEATING
& COOLING" mode
/ Disabled
"BOOST" mode
"BOOST" mode
acvated
Operang at full power
in "SMART" mode
Disabled
"SMART" mode
"SMART" mode
acvated
Operang at medium
power in "SILENCE"
mode
Disabled
"SILENCE" mode
"SILENCE" mode
acvated
/ Disabled
Alarm Alarm enabled / Disabled
Padlock Keypad locked / Disabled
"TIMER" ON
Conguraon in
progress
/ Disabled
"TIMER" OFF
Conguraon in
progress
/ Disabled
°F°C
Celsius/Fahrenheit
Selected temperature
unit
/ Disabled
2.3 I Operaon
• Check that there are no tools or other foreign objects in the machine,
• Ret the panel providing access to the technical part (see § "5.3 I Dimensions and marking"),
• Set the valves as follows: valve B wide open, valves A, C, D and E closed.
: Water inlet valve
: By-pass valve
: Water outlet valve
: Water inlet adjustment valve (oponal)
: Water outlet adjustment valve (oponal)
• An incorrect by-pass seng may cause the heat pump to malfuncon.
• Check that the hydraulic connecons are correctly ghtened and that there are no leaks.
• Check that the appliance is stable.
• Turn on the water ow (by acvang ltraon).
• Close valve B gradually so that the lter pressure is increased by 150g (0.150 bars).
• Open valves A, C and D fully then valve E by half (the air which has built up in the heat pump condenser and the
ltraon circuit will bleed out). If valves D and E are not present, open valve A wide and close valve C by half.
• Connect the power supply to the heat pump.
• The heat pump is on standby.
• Press .
• Set the desired temperature (called the "temperature setpoint" ) (see § “2.4.2 Changing operang mode”).
Aer the start-up steps for your heat pump:
• Shut down the water circulaon temporarily (by stopping the ltraon or closing valve B or C) to check that your
appliance stops aer a few seconds (via the acvaon of the ow switch).
