25
3.5 I Installing the pH minus injec on and suc on hoses
• When handling chemical products, always use appropriate safety equipment
(safety glasses, gloves and jacket).
The peristal c pump rotates in the clockwise direc on. The acid (pH minus) is therefore fed into the le side of the pump
and injected into the tank from the right. The direc on of ow of the pump can be iden ed on the pH Link or Dual Link
module from the two dedicated arrows.
pH Link
Dual Link
POD kit
INPUT
OUTPUT
: Support p
: Ceramic weight
: pH minus container
: Suc on hose
: Peristal c pump
: Injec on hose
: Injec on check valve
3.5.1 Installing the pH minus injec on line
• Remove the protec ve cover from the peristal c pump, see gure
.
• Cut a suitable length of hose from the coil supplied to connect the peristal c pump to the injec on check
valve of the POD kit.
• Unscrew the connector cap and a ach the hose to the connector at the outlet of the peristal c pump, see
gure
.
• A ach the other end of the hose to the injec on check valve of the POD kit, see gure
.
EN
