3.2.3 Installing the POD kit on the pipe
• For a Ø50 mm pipe, use the adapter labelled "EU". Clip the 2 parts of the POD kit collar together around the
pipe. Make sure that the adapter is properly centred according to the guides; the adapter must stay in this
posi on once all parts have been assembled. Do not use this adapter for a Ø63 mm pipe, see gure
.
• Install the bo om and top collars of the POD kit on the pipe according to the posi on of the holes and the
water ow direc on (follow the arrows), see gure .
• Posi on the top part with its di erent components in the direc on shown by the foolproo ng key, align the
point of the compression ring with the arrow of the bo om collar and ghten the compression ring
well ( ghten by hand only!), see gure .
• To determine whether ghtening is correct, check that the compression ring is level, see gure .
Pipe adapter Ø50 mm (marked "EU")
Bo om collar Ø63
INPUT
OUTPUT
Direc on of water ow
Foolproo ng key
