2❷ Installing the salt water chlorinator
2.1 I Installing the electrolyc cell
• The cell must always be the last element placed on the pool return pipe (see § “2.1.1. Installing the cell
and the sensor holder (depending on model)”).
• It is always recommended to install the cell on a by-pass. This assembly is mandatory if the ow is in
excess of 18 m³/hour to avoid head loss. A ow regulaon valve must be included.
• When the cell is installed on a by-pass, t a check valve downstream from the cell instead of a manual
valve, to avoid any risk of incorrect conguraon and poor circulaon inside the cell.
2.1.1. Installing the cell and the sensor holder (depending on model)
• The cell must be installed on the piping aer the ltraon system, aer any measurement sensors, and aer any
heang system.
• The cell's installaon must allow easy access to the installed electrodes.
• Two valves must be installed for isolang the cell from the rest of the installaon, so that maintenance tasks can be
performed without emptying the pool.
Outlet
Inlet
Installing the chlorinator on a by-pass (recommended) Direct installaon
Control box
Cell
Flow switch
Filter
Electric terminal block
Sensor holder + pH sensor and/or ORP sensor*
pH pump*
Container of pH-minus*
Direct installaon is
only possible if the ow rate
is going up.
(*depending on model)
• Respect the water ow direcon indicated on the cell.
• The circulaon system must guarantee the minimum required ow (see§ “1.2 I Technical
specicaons”).
• For Ø50 mm pipes, use glue-on PVC adapters of the corresponding diameter.
• Connect the cell power cord following the wire colour codes (red, yellow, and orange connectors) and then ret the
protecve cap (see § “2.1.3. Connecng the cell to the control box”).
