14
Designer Wall Hood Installation
DESIGNER WALL HOOD INSTALLATION
8. Find the center of the wall where you are installing the hood. Make sure there
is sufficient bracing to hold the weight of the hood. Mark your center line and
measure out from the center to find your two mounting points. Make sure your
mounting points are level when you mark them. It is recommended to install the
hood directly into wood supports. Figure 7
9. Mark the mounting points and install the two mounting screws provided leaving
the heads out ¼˝ to mount the hood. Figure 8
10. Mount the main body of the hood to the two screws and screw into place.
Figure 9
Figure 7
Figure 8
Figure 9
Screw
+0”/-2”
