13
Designer Wall Hood Installation
DESIGNER WALL HOOD INSTALLATION
5. Make your electrical and ducting connections. Try and minimize the use of
elbows. More elbows and longer runs create higher static pressure. The hood
comes with a grounded three prong plug that can be plugged into a 20amp.
circuit. The cord is 36” long. Figure 5
6. Install the transition piece securing it with screws provided.
7. Connect the ducting to the transition piece using foil-backed tape to hold it into
place. Attach the ducting to the range hood.
Figure 4 Figure 5
Screw
