EN

DESCRIPTION OF PARTS (FIG. B)

ASSEMBLY

1. Open the top of the dirt tank, take out all components, and place the tank upside down

on at surface.

2. To properly assemble the caster, insert the metal pin into the designated spot on the

base of the body (Fig. 1). Press the caster unl you feel resistance.

3. Fasten the top cover by closing the plasc clamp (9, Fig. A).

4. Insert the exible sucon hose with spray tube into the inlet opening (Fig. 2).

REMOVAL OF DRY DIRT AND DEBRIS

1. To use the vacuum cleaner for removing dust and other dry debris, rst place the HEPA

lter on the lter support, fasten the lter cover (Fig. 3), and then insert bag into the

vacuum cleaner at the inlet opening (Fig. 5).

2. Fasten the top cover by closing the plasc clamp (9, Fig. A).

3.

Aach the exible sucon hose to the inlet opening (Fig. 2) and ax an appropriate

aachment. Make sure it is ghtly ed.

4. To remove the aachment, just pull it o.

5. Connect the power cord to the power source, and then turn on the vacuum cleaner by

pressing the switch (3, Fig. A).

6. To regulate the air ow, turn the force control knob (4, Fig. A).

7. To remove the HEPA lter, open the plasc clamps (9, Fig. A) and take o the top cover.

Next unfasten the lter cover, take out the HEPA lter from the lter support and remove

the bag from the inlet opening inside the vacuum cleaner.

8. To connect the sucon tubes, aach them to the exible sucon hose with spray tube

(Fig. 10). Ensure that they are rmly secured. To remove the sucon tubes, press the

release buon (a, Fig. 9) and pull.

9. To aach the extension hose (9, Fig. B), secure it to the exible sucon hose with spray

tube (1, Fig. A). Ensure that it is rmly secured. To remove the extension hose, pull it out.

BLOWER FUNCTION

1. To use the blower funcon place the HEPA lter on the lter support, fasten the lter

cover (Fig. 3), and then insert bag into the vacuum cleaner at the inlet opening (Fig. 5).

2. Fasten the top cover by closing the plasc clamp (9, Fig. A).

3. Aach the exible sucon hose to the outlet opening (5, Fig. A) and ax an appropriate

aachment. Make sure it is ghtly ed.

4. To remove the aachment, just pull it o.

5. Connect the power cord to the power source, and then turn on the vacuum cleaner by

pressing the switch (3, Fig. A).

6. To regulate the air ow, turn the force control knob (4, Fig. A).

1. Flexible sucon hose with spray tube

2. Sucon tubes

3. Carpet and rug cleaning nozzle

4. Upholstery cleaning nozzle

5. Crevice nozzle

6. Universal nozzle

7. Dry vacuum cleaning bag

8. Sponge lter

9. Extension hose

10. HEPA lter
