33
4. Clean the platen with the alcohol moistened swab. Clean from the center out until the all of the
roller’s surface has been cleaned. If there has been heavy adhesive build-up or you have been
having labels catch and bind in the printer, then repeat cleaning with a new swab to remove
residual diluted contaminates. Adhesives and oils, for example, may be thinned by the initial
cleaning but not removed.
5. Install the platen in the printer. Discard the cleaning swabs after use - do not reuse.
6. Make sure the bearings and gear are on the shaft of the platen as shown.
7. Align the platen with the gear to the left and lower it into the printer’s bottom frame.
8. Rotate the tabs back and snap them into place.
