Basic Operation 2 - 3
Help table for the correct setting:
Antenna Solutions for Use in Germany
The integrated antenna solutions are based on the prevailing IEEE 802.11 standard. This standard allows wire-
less data transfer at rates from 1 Mbps to 54 Mbps using the 2.4 GHz and 5 GHz frequency band (300 Mbps if
using IEEE 802.11n).
Example configuration of the transmission power using the Laird Connection Manager program:
Figure 2-2
Configuring the antenna transmitting power with Laird (example)
Laird Connection Manager for WLAN Configuration
The Laird Connection Manager is used to set up the WLAN configuration for the 8585.
Launch this connection manager with a double tap on the Laird Connection Manager icon on the desktop:
WARNING! In Germany according to regulations published in the gazette 89/2003 of the RegTP
(regulating body for telecommunications and mail), now: “Bundesnetzagentur” -
Federal network agency for electricity, gas, telecommunications, post and railway -
the maximum permissible transmitting power, EIRP (equivalent isotropically radi-
ated power), in the 2.4 GHz frequency band is set at 20 dBm.
The transmitting power of the integrated Zebra antenna (Zebra 3 dBi) must be set to
50 mW (17 dBm) so that the EIRP limit value is adhered to when using the antenna.
WARNING! WLAN configurations may only be modified by qualified IT technical staff.
