1 - 2 8585/8595 Vehicle-Mount Computer User Guide
Initial Operation of the Device
Area of Application: Not for use in life-support systems or critical safety systems
The device is not designed for use in life-support systems or critical safety systems where system malfunction
can lead to the direct or indirect endangerment of human life. The operator shall take full responsibility for
using the device in these situations.
The device cannot be used in combination with safety functions for machines and equipment which have to
conform to the requirements of EN 954-1.
Installation/Initial Operation
Installation of the 8585 on a vehicle must be performed in accordance with Chapter 3: Installing the Computer.
Specifically, special attention must be paid to the various electrical potentials of the vehicle. Some vehicles
have a chassis that is connected to one of the battery supply lines (DC+ or DC-), while most electrically-driven
forklift vehicles have floating chassis, connected to neither DC+ or DC-. Refer to Vehicle Applications (such as
forklifts) on page 3-2 for required wiring of vehicle power and fusing for the 8585.
Risk of injury during transit or installation
The unit could fall during transit or installation and cause injury. Always ensure that there are two persons
available when installing or removing the device.
Choice of Location: Observe the Protection Class
The ambient conditions at the point of installation must comply with the device's protection class.
Supply of Fresh Air: Avoid overheating the unit
The 8585 is based on a passive cooling concept. As a result, the waste heat which is produced inside the
device is emitted over the surface of the housing. For this system to function properly, sufficient fresh air circu-
lation is required. Never install the system in a closed environment where the cooling air is unable to dissipate
accumulated heat to the outside.
If the 8585 is not able to draw in fresh cooling air, this may cause overheating and severe damage to the unit.
The maximum allowed ambient temperature for the system needs to be taken into account for the concrete
application area.
Install an easily accessible disconnecting device
The device is not supplied with a disconnector (switch) that can be accessed externally. The power supply
connector is therefore used as a disconnector. Therefore it needs to be easily accessible.
If it is necessary to establish a fixed connection, an easily accessible disconnecting device (e.g. a switch such
as a circuit breaker) should be installed close to the device. Ensure that the power cable is laid so that it is
mechanically protected.
Laying Power Supply Cables: Observe the local installation regulations
The power supply cables must be laid in accordance with the applicable local installation regulations.
Ensure that no persons are injured in case the mounting bracket breaks
The 8585 may in no case be installed in such a way that persons can be injured during a breaking of the
mounting bracket (e.g. fatigue break).
If the device is mounted in a place where people can be injured if the bracket should break, appropriate safety
measures must be put in place (e.g. install a security cable in addition to the device bracket).
