Watercraft operation

33

EJU40003

Watercraft operation modes

EJU45900

T.D.E. (thrust directional enhancer)

The T.D.E. is a function for slightly lifting or

lowering the reverse gate from the neutral po-

sition to operate the watercraft at very low

speeds when the engine is running at idling

speed.

This function can be used only when the wa-

tercraft is in neutral.

TIP

While the watercraft is shifted into forward,

the “TRIM/T.D.E.” switch controls the electric

trim system. (See page 31 for information on

the electric trim system.)

Activating and deactivating the T.D.E.

The activation of the T.D.E. can be confirmed

by the T.D.E. indicator on the multifunction

information center.

To activate the T.D.E.:

(1) Shift into neutral.

(2) Push the upper side of the “TRIM/T.D.E.”

switch to move forward at a very low

speed or push the lower side of the

“TRIM/T.D.E.” switch to move in reverse

at a very low speed.

TIP

While the T.D.E. is activated, the “N” (neutral)

shift indicator will be displayed and “0” will be

displayed on the speedometer.

To deactivate the T.D.E.:

Perform one of the following operations. The

T.D.E. indicator disappears and the T.D.E. is

deactivated.

 Squeeze the throttle lever.

 Squeeze the RiDE lever.

 Push and hold the “CRUISE/NO WAKE”

switch.

 While moving forward at a very low speed,

push the lower side of the “TRIM/T.D.E.”

switch.

 While moving in reverse at a very low

speed, push the upper side of the

“TRIM/T.D.E.” switch.

TIP

The T.D.E. is also deactivated when the en-

gine is stopped.

EJU45911

No-wake mode

The no-wake mode is a function that main-

tains the engine speed at a fixed setting for

operating the watercraft at low speeds. While

the watercraft is operating in no-wake mode,

the engine speed can be adjusted to one en-

1 T.D.E. indicator

2 Forward operation at a very low speed

3 Reverse operation at a very low speed

14.3v

RPM

x1000

km/h

T.D.E. FORWARD

T.D.E. REVERSE

T.D.E. FORWARD

1

3

2

1 “TRIM/T.D.E.” switch

1

UF5R70E0.book Page 33 Friday, October 4, 2024 9:02 AM
