Appendix
Rio3224-D3 Rio1608-D3 Reference Manual
39
General Specifications
The contents of this manual apply to the latest specifications as of the publishing date. To
obtain the latest manual, access the Yamaha website then download the manual file.
*1. Measurement position: 1 m from the front of the unit
*2. Multiple AC power cords which have different kinds of plug shapes may be included depending on the region.
Rio3224-D3 Rio1608-D3
Number of Analog Inputs 32 16
Number of Analog Outputs 16 8
AES/EBU 8-out 0
PHONES 1
Sampling
Frequency
External 44.1 kHz / 48 kHz / 88.2 kHz / 96 kHz ±200 ppm
+4.1667%, +0.1%, −0.1%, −4.0% ±200 ppm
Signal Delay Less than 1.7 ms
Rio-D3 INPUT to Rio-D3 OUTPUT connect with DM7 using Dante, Fs=96 kHz.
Dante Receive Latency set to 0.25 msec
Power Requirements 100–240 V, 50/60 Hz
Power Consumption 100 W 60 W
Heat Dissipation 86 kcal/h 52 kcal/h
Dimensions W x H x D 480 x 220 x 370 mm 480 x 132 x 370 mm
Weight 13.2 kg 9.4 kg
NC value
*1
Fan Speed
LOW
20 15
Fan Speed
HIGH
30 25
Operating Temperature Range Min: 0 °C, Max: 40 °C
Storage Temperature Range Min: −20 °C, Max: 60 °C
Accessories
Owner's Manual, Power cord × 2
*2
,
Open-Source Software License (only in English)
