Screens
Rio3224-D3 Rio1608-D3 Reference Manual
21
NW PORT (Network port)
Network port is used for the control circuit. For more information on communications, refer to
section (3) of “Communication methods
” on page 35.
The following table provides a description of the items and parameters that can be selected,
and the values that can be set.
DANTE PORT
Dante port is used for the control circuit. For more information on communications, refer to
section (2) of “Communication methods” on page 35.
The following table provides a description of the items and parameters that can be selected,
and the values that can be set.
SYSTEM menu
This menu displays the unit version number, the SYSTEM/SYNC status, and other
information.
While the SYSTEM screen is displayed, turn the encoder with switch to select a parameter.
The screen displays the following items. You cannot modify these settings on the Rio-D3.
Item Description
Setting value (“*” represents
the default value.)
NETWORK MODE Selects the IP address setting mode for the
network port. This IP address is used when
remotely controlling the unit from a computer,
or when updating the firmware.
DHCP, STATIC IP*
IP ADDRESS Specifies the IP address for the network port
(when STATIC IP is specified).
192.168.0.2*
In the case of DHCP, the
current value is shown.
SUBNET MASK Specifies the SUBNET MASK for the network
port (when STATIC IP is specified).
255.255.255.0*
In the case of DHCP, the
current value is shown.
DEFAULT GW Specifies the DEFAULT GATEWAY for the
network port (when STATIC IP is specified).
192.168.0.1*
In the case of DHCP, the
current value is shown.
Item Description
Setting value (“*” represents
the default value.)
NETWORK MODE Selects the IP address setting mode for the
Dante port. This IP address is used when
remotely controlling the unit from a computer,
or when updating the firmware.
DHCP *, STATIC IP
IP ADDRESS Specifies the IP address for the Dante ports
(when STATIC IP is specified).
(determined by DHCP or Link
Local)*
SUBNET MASK Specifies the SUBNET MASK for the Dante
ports (when STATIC IP is specified).
(determined by DHCP or Link
Local)*
DEFAULT GW Specifies the DEFAULT GATEWAY for the
Dante port (when STATIC IP is specified).
(determined by DHCP or Link
Local)*
Item Description
NAME Indicates the Dante device label.
MODEL VER Indicates the firmware version of the Rio-D3 unit.
HAAD VER Indicates the HAAD FPGA version of the Rio-D3 unit.
DANTE VER Indicates the Dante versions. (Dante firmware version, FPGA version, Yamaha
software version)
SYSTEM Indicates the system status of the Rio-D3. For details on the messages, refer
to “SYSTEM messages
” on page 36.
SYNC Indicates the synchronization status of the Rio-D3. For details on the
messages, refer to “SYNC messages
” on page 37.
SYSTEM
NAME MODEL VER HAAD VER
SYNC SYSTEM DANTE VER
