vMON-Series
Page 37
Disk or to via a USB connection to a PC.
9. USB Upgrade: You may upgrade the various firmware parts of the monitor
via USB. The firmware to be upgraded includes FPGA, LUTs, OSD, EDP, APP,
or all of the firmware.
10. DHCP: Network setting DHCP may be turned ON or OFF.
11. Gateway: The network Gateway may be set as follows:
a. 255.255.255.000: Set a custom Gateway.
b. 0: The Default Gateway is set to 192.168.001.001.
12. Subnet Mask: The Subnet mask settings are:
a. 255.255.255.000: Set a custom subnet mask.
b. 0: The default Subnet Mask is 255.255.255.000.
13. IP Address: The default IP Address is 192.168.1.155.
Commonly Used Setups
The many settings in the menus of this monitor provide great flexibility in setting it
up for many different tasks. However, this may be daunting for a new customer.
This section provides step by step examples of how to perform some basic setups.
Input Source Selection, Single Picture Mode
Switching to view another source may involve more than simply switching the input
source. It may also require the changing of various parameters such as gamut,
EOTF, and so on. The vMON monitors make switching inputs simple, but setting up
each input first requires a few steps. For example to set SDI 3 as the input source
for a full screen display, use the following steps:
1. Connect the signal to be monitored to the SDI 3 BNC.
2. Press the MENU/EXIT button and then go down to the Source submenu.
3. In this menu, set the Display Mode to Single, the Input Mode to Single
Input, and the Win1 Source to SDI3.
4. Go to the Function submenu and set S1 to Config1.
5. Go to the Config submenu, set Save to Config1 and press the Volume
Knob to save.
6. After saving, from now on pressing the S1 button will cause SDI 3 to display.
Input Source Selection, Quad Split Mode
To set Win1 to display SDI 1, Win2 to display SDI2, Win3 to display SDI3 and Win4
to display HDMI, use the following steps:
1. Connect the four signals to be monitored to the appropriate inputs on the
monitor.
2. Press the Menu/Exit button and then go down to the Source submenu.
