IR T2 Infrared Transmitter
Infrared Transmitter Specifications
Model IR T2
Dimensions, Weight: 9.0" W (229 mm) x 3.8" D (97 mm) x 1.4" H (36 mm), 0.84 lb. (0.38 kg)
Color: Black
Power Supply: Supplied TFP desktop style international certified power supply with IEC line cord,
100-240 VAC input, 50-60 Hz, 18 W; 48 VDC output
DC Power Input: 2.1 mm ID barrel connector, 48 VDC, 0.2A, center positive
Power Indicator: Green LED
Sleep/Power Save Mode: Shuts o carrier when no audio is present for 12 minutes
Modulation: FM Wideband, ±50 kHz deviation max, 50 μS pre-emphasis
Emitter IR Power: 0.7 W
Baseband Frequencies: 2.3, 2.8, 3.3, 3.8 MHz
Channels: Indicators: Yellow LEDs indicate whether 2.3/2.8 MHz or 3.3./3.8 MHz baseband
frequencies are selected
Coverage Area: Up to 18,000 sq. ft (1,673 sq. m) in single-channel mode with the RX22-4 receiver
Up to 11,500 sq. ft (1,068 sq. m) with the RX20 receiver
Microphone input: 3.5 mm, stereo jack with signal and bias connected to tip, electret microphone
compatible (6 VDC bias supply with 2.7 k ohm series resistor)
Microphone gain adjust: Rotary 10 dB range
Microphone channel switch: Selects microphone input to Ch. A or Ch. B
Audio Inputs / Controls: Line inputs: Phoenix style connector jack for Ch A and Ch B accept line level,
balanced or unbalanced audio
Audio indicators: One yellow LED per channel. Lights up and stay on steady with minimum audio level.
Indicators On/O: Momentary contact switch turns on/o indicator lights
Frequency Selection: Press and hold momentary contact switch to change carrier frequency group.
Signal-to-Noise Ratio: 70 dB (line input)
Frequency Response: 95 Hz to 17.6 kHz, -3 dB re 1 kHz (line inputs)
125 Hz to 17.0 KHz, -3 dB re 1 kHz (microphone input)
Total Harmonic Distortion: <1% (1 kHz, nominal deviation, line or microphone input)
Control/Monitoring: 3-wire RS-232 bus, standard ASCII commands/replies, 115200 Baud rate (8N1).
See the IR T2 Programmers Guide for more information.
Operating Requirements: 32°-122°F (0-50°C)
Mounting Kit: Wall or Ceiling mount: BKT 024 Omnidirectional mount
Warranty: 5 Years
Approvals: CE, FCC, Industry Canada, WEEE, RoHS, CB Scheme, RCM, PSE
Compatible Receivers: WIR RX22-4, IR RX20
NOTE: Specifications subject to change without notice�
Visit our website for the latest specifications and publications: www�williamsav�com
Hereby, Williams AV declares that the infrared equipment is in compliance with Directives
2014/30/EU, 2014/35/EU and other Union harmonization as applicable. The full text of the
EU declaration of conformity is available by contacting Williams AV at the following email
address: regulatory@williamsav.com
