11
IR T2 Infrared Transmitter
IR T2 Blink Codes
The IR T2 has indicator lights on the back that display the current settings or alert that there
is an error.
LIGHT PATTERN MEANING
All visible LEDs on the back of the unit are on for 2
seconds
Unit has rebooted
When enabling the visible LEDs, the CH A audio LED
blinks twice before displaying audio level
CH A audio is transmitting on all infrared emitters
When enabling the visible LEDs, the CH B audio LED
blinks twice before displaying audio level
CH B audio is transmitting on all infrared emitters
When enabling the visible LEDs, the CH A and CH B
audio LED blinks twice together before displaying audio
level
CH A audio is transmitting on half of the infrared
emitters, CH B audio is transmitting on half of the
infrared emitters.
When enabling the visible LEDs, neither CH A nor CH B
audio LEDs blink
Unit is in sleep mode and is not transmitting
Power LED rapidly blinks Unit has encountered an error. See the IR T2
Programmer’s Guide for how to get more information
Power LED rapidly blinks, and then power LEDs on for
two seconds
Unit is rebooting repeatedly in an attempt to recover
from errors. See the IR T2 Programmer’s Guide for how
to get more information
Power LED fades from brightly lit to dim No audio is detected by the system. Troubleshoot audio
source or audio connections.
NOTE: The indicator lights can all be turned o AFTER initial set-up to allow for less conspicuous
operation� Press and release the LED on/o button on the back of the device�
Mounting Options
BKT 024 - Universal wall / ceiling mount (included)
MLB 003 - Linking bar for stacking transmitters
STD 007 - Tabletop tripod stand
The IR T2 can be mounted on any camera tripod stands with a 1/4” - 20 threaded connector.
Do not paint the front of the IR T2.
Accessories
MIC 027 - Hand-held unidirectional microphone
MIC 049 - Omnidirectional conference microphone
MIC 090 - Lavaliere microphone
MIC 100 - Rear-wear headset microphone
WCA 105 - RCA to Phoenix cable
Optional Receivers
WIR RX22-4 Receiver
IR RX20 Receiver
